Uniview UNV
MW7815-FI-EB
Ürün Kodu : MW7815-FI-EB
LED Display Unit
Module:
Pixel pitch (mm)P1.5
Resolution (W*H)96*216
Dimensions (W*H*D)(mm)150*337.5*2
Unit:
Dimensions (W*H*D)(mm)600*337.5*27.2
Modules component (W*H)4*1
Resolution (W*H)384*216
Weight (kg/pcs)4.3
Area (m²) 0.2025
Pixel density (pitch/m²)409600
Surface evenness (mm)≤0.1
Cabinet material,Die-cast aluminum
- Ürün Özellikleri
- Tavsiye Et
- Resimler
- Döküman
-
Model MW7815-FI-EB Module Pixel pitch (mm) P1.5 Resolution (W*H) 96*216 Dimensions (W*H*D)(mm) 150*337.5*2 Unit Dimensions (W*H*D)(mm) 600*337.5*27.2 Modules component (W*H) 4*1 Resolution (W*H) 384*216 Weight (kg/pcs) 4.3 Area (m²) 0.2025 Pixel density (pitch/m²) 409600 Surface evenness (mm) ≤0.1 Cabinet material Die-cast aluminum Optical Single pixel brightness correction Support Single pixel color correction Support Brightness (nits) 600 Color temperature (K) 3000 to 10000 adjustable Viewing angle (H/V) 160°/140° Center distance deviation of LED <2.5% Brightness uniformity ≥97% Color uniformity (Cx,Cy) ±0.003Cx, Cy Contrast ratio 4000:1 Processing performance Grayscale 16bit Scanning mode (s) 54 Drive mode Constant current driving Frame frequency (Hz) 50/60 Refresh rate (Hz) 3840 Electrical Power supply (V) AC 100 to 240V, 50/60Hz Average power consumption (W/m²) ≤207 Max. power consumption (W/m²) ≤463 General Maintenance mode Front maintenance Ingress protection IP5X Operating temperature/humidity (°C/RH) -10°C to +40°C, 10% to 85% RH, non-condensing Storage temperature/humidity (°C/RH) -10°C to +55°C, 10% to 90% RH, non-condensing LED lifetime (H) 100000 -
Teknik Özellikler Veri Dosyası
